4*35sqmm Electrical Circuit Breaker Fuse Box Model M1 For Lighting Pole Use High Quality Body Made of Polyamide Resin with IP54 Protection Rate and IK 09

4*35sqmm electrical circuit breaker Fuse Box Model M1 for lighting pole use  high quality body made of polyamide resin with IP54 protection rate and IK 08.

This Fuse box for lighting pole use high quality body made of polyamide resin with IP54 protection rate and IK 09. The body made of polyamide resin 6 self-extinguishing and infrangible. We devoted ourselves to fuse box many years, covering most of Europe market. We are expecting become your long-term partner in china.

1, Product introduction of the 30-80w led garden light

1-Body made of polyamide resin 6 self-extinguishing and infrangible.
 2-Moulded connector made of polyamide resin 6 self-extinguishing.
 3-Pressed terminals made of 3 ways zinc electro-alloy. Fast assembling on DIN rail. Single connection of the wires by inox screws.
 4-Double DIN rail to allow the 4 cables 3 ways terminal strip 4*35sqmm plus one or two fuse carriers (or MCB)
 5-Voltage 450V max. Current 63A.
 6-Pole recessed mounting diameter min. 140mm.
 7-The min. dimensions of the door opening of the pole should be 100*400mm.
 8-Body and terminals class 2 according to CEI64-8/4 standards.
 9-Protection rate IP54 along the frame; IK 08 according to CEI EN 50102 standards.
 10-Any RAL colour on request.

2, Product Feature And Application of Fuse Box Model M1

This Fuse Box Model M1 was made up with polyamide resin 6 self-extinguishing and infrangible. It was applicated into urban roads and street lighting poles. We devoted ourselves to lighting many years, covering most of Europe and Asia, middle east market. We are expecting become your long-term partner in China.
